BTECH high pressure water jet machine

water jet machine BTECH water jet cutting machine For matel, plastic,and so on material cutting . BTECH has three levels of pump pressure: 270Mpa (40kpsi), 320Mpa(47kpsi), and 380Mpa(55kpsi)One of these pumps combinded with one of the CNC cutting tables makes a full system. We have tables such as 4'x4', 4'x8', 5'x10', 6'x12', 10'x 40' etc.Below are some Example modes of BTECH waterjet machine and their specification.Example Model WC4WA1313HWC5WA3020HWC4WA2514UWC5WA4020UStyleOverpassCantileverExample PictureMax work piece Size1.3m X 1.3m (4x 4)3m X 2m (9.8x6.5)2.5m X 1.4m (4x8)4m X 2m (13x6.5)Max Z-axis adjustment150mm (6") manual NC SYSTEMServo MotorServo MotorServo MotorServo Motorposition Accuracy0.02mm (0.001)0.02mm (0.001)0.02mm (0.001)0.02mm (0.001)Re-position Accuracy0.01mm (0.0004)0.01mm (0.0004)0.01mm (0.0004)0.001mm (0.0004)Cutting Accuracy0.1mm (0.004)0.1mm (0.004)0.1mm (0.004)0.1mm (0.004)Max working pressure320Mpa (47kPsi)380Mpa (55kPsi)320Mpa (47kPsi)380Mpa (55kPsi)Max pressured Water Flow Rate3.0L/min (47kPsi)3.5L/min (55kPsi)3.0L/min (47kPsi)3.5L/min (55kPsi)Multi cutting head option1 only (47kPsi)Max 2, each of 0.15mm(0.006") orifice1 only (47kPsi)Max 2, each of 0.15mm(0.006") orificePower Supply220/380/400/460VAC, 50/60Hz, 25/32/40kwForm SizeLxWxH(m)2.3x2.2x1.8 1.6x0.8x1.4 0.7x0.5x1.84.2x3.3x1.8 1.6x0.8x1.4 0.7x0.5x1.83.4x2.2x1.8 1.6x0.8x1.4 0.7x0.5x1.85.2x2.8x1.8 1.6x0.8x1.4 0.7x0.5x1.8Weight2500kg3200kg3000kg3400kg
