Abrasive Water jet granite cutting machine

We make complete CNC water jet cutting system. We are leader in China waterjet cutting machine business. There are overpass water jet cutter and cantilever waterjet cutter machine. Water jet machine table sizes can be from 1300x1300mm, 1400x2500mm, 1500x3000mm 2000x3000mm, up to 12mm x3m. There is also abrasive water jet cutting machine. The water jet pump produces 400Mpa pressure. The waterjet machine can cut mild steel as thick as 3 inches. Other materials can be cut: all kinds of metal, marble, granite, ceramic tile, robber, plastic, cloth, wood, paper and food such as meat. Water jet cutter is cold cutting machine, so it does not create heat affect zone (HAZ) when cutting metal, and does not burn and create poison gas when cutting plastic or rubber. Pump Type Dual plunger reciprocal intensifier Max pressure 400Mpa (55kpsi) Pump cooling typeWater circulation or electrical chiller Motion system Ball screw and linear guide Motion driver Servo motors Max travel speed 10m/min (32ft/min) Position repeatability 0.03mm/m (0.0004/ft) Controller type PC with software in Microsoft Windows Z axis travel 150mm (6) driven by motor Orifice supported 0.15mm- 0.33mm Multi-head support Supports 1-3 cutting heads Power requirement 3 phase, 220-480VAC, 45kw, 50HP Cutting table size Choose from: 1300x1300mm, 1500x2000mm, 1500x2500mm 1500x3000mm, 2000x3000mm, 2000x4000mm Call for custom size order.
